Two-speed exhaust fan motor in box casing with carbon filters

Activated carbon control unit with 2-speed belt transmission.

CHARACTERISTICS
- Aluminum tubular structure
- Double paneling in plasticized sheet metal, removable and complete with gasket
- Internal soundproof insulation in expanded polyurethane
- Inspection of transmission side for maintenance
- Belt tensioning slide
- Motor unit: fan with anti-vibration supports
- 48 mm thick pleated synthetic filters with 85% gravimetric efficiency (G3) - EN 779 class
- Pocket filters 85% colorimetric efficiency (F7) class EN 779
- E207 type activated carbon filters

Limitations of use:
Maximum temperature of the transported fluid: +60° C
Maximum humidity: 80% RH
Assembly: internal

DATASHEET

Flow rate 2,100/3,000 m³/h

Dimensions : L.67 x D.215 x H.67 cm
Power : 0.37 / 1.1 kW
Voltage : 400 V / 3 / 50 Hz
Current : 1.2 / 2.7 A
Hst : 140 / 200 Pa
Filters : 9
Weight : 170 kg

Flow rate 3,200/4,500 m³/h

Dimensions : L.98 x D.215 x H.67 cm
Power : 0.6 / 1.7 kW
Voltage : 400 V / 3 / 50 Hz
Current : 1.8 / 4.3 A
Hst : 140 / 200 Pa
Filters : 14
Weight : 215 kg

Flow rate 4,200/6,000 m³/h

Dimensions : L.128 x D.215 x H.75 cm
Power : 0.75 / 2.2 kW
Voltage : 400 V / 3 / 50 Hz
Current : 2.1 / 5.2 A
Hst : 180 / 250 Pa
Filters : 18
Weight : 310 kg

Flow rate 5,300/7,500 m³/h

Dimensions : L.159 x D.220 x H.85 cm
Power : 1 / 3 kW
Voltage : 400 V / 3 / 50 Hz
Current : 2.8 / 6.6 A
Hst : 180 / 250 Pa
Filters : 23
Weight : 350 kg

Flow rate 6,300/9,000 m³/h

Dimensions : L.128 x D.220 x H.98 cm
Power : 1 / 3 kW
Voltage : 400 V / 3 / 50 Hz
Current : 2.8 / 6.6 A
Hst : 140 / 200 Pa
Filters : 28
Weight : 390 kg

Flow rate 8,400/12,000 m³/h

Dimensions : L.128 x D.230 x H.128 cm
Power : 1.2 / 4 kW
Voltage : 400 V / 3 / 50 Hz
Current : 3.7 / 8.3 A
Hst : 140 / 200 Pa
Filters : 36
Weight : 440 kg
