Meat multideck display fridge VULCANO, depth 80 cm

Ref: RF_02003

Made in italy

1.959,00 € (price excluding 22% VAT)

€2,389.98 (price with 22% VAT included)

Vulcano model refrigerated wall display. Designed for displaying and preserving meat. Designed for markets, butchers and delicatessens. Different versions available with different lengths depending on needs.

Length
Ask a Quote

100% secure payments
account_circleSend to a friend > Information request
Meat multideck display fridge VULCANO, depth 80 cm

Meat multideck display fridge VULCANO, depth 80 cm


Vulcano model refrigerated wall display. Designed for displaying and preserving meat. Designed for markets, butchers and delicatessens. Different versions available with different lengths depending on needs.

Send to a friend


I accept the terms of the privacy policy


Ask a Quote

VERTICAL REFRIGERATED PLUG-IN DISPLAY, COMPACT, SUITABLE FOR DISPLAYING AND STORAGE OF FRESH PRE-PACKAGED PRODUCTS

Ecological, reliable, hygienic, completely customizable. Suitable for all sales surfaces

DEPTH 80 cm

Conceived with particular attention aimed at ease of installation and optimization of the cleaning system , guaranteed by easy access to the internal parts. The products on display are always kept at an ideal temperature , thanks to the flow of refrigerated air and a well-sized refrigeration system . It is a product with low energy consumption and low environmental impact : the tub is made without the use of CFCs . All phases, from design to production, have been taken care of in detail: technology and design made in Italy .

CHARACTERISTICS :
• Compact but with a large display surface
• Suitable for small, medium and large distribution
• “Made in Italy” technology, design and production
• Easy installation
• Optimization of the cleaning system
• Low energy consumption
• Low environmental impact
• Bathtub made without the use of CFCs
• Ventilated refrigeration
• Possibility of customizations on request

STANDARD EQUIPMENT :
• Thermoformed and insulated sides (4 cm thick each) with tempered glass side
• Electronic control panel
• Electric defrost
• Top lighting with pink neon lamp
• Manual self-retracting night curtain
• 4 shelves in non-toxic white post-painted sheet metal or in stainless steel (for stainless steel version), adjustable in height, equipped with price holder, without lighting, without product holding grids
• R452A valve in both the version with group and without group

AVAILABLE VERSIONS :
• With built-in unit (equipped with automatic condensation water recovery and evaporation system, via stainless steel coil)
• With connection to remote compressor: on request
• Stainless steel version: on request

AVAILABLE COLORS :

INSERT IN THE NOTES , WHILE CONFIRMING THE ORDER, THE COLOR OF THE SHOWCASE YOU PREFER FROM THE POSSIBILITIES LISTED ABOVE. IF YOU DON'T CHOOSE A COLOR WE WILL DELIVER TO YOU THE FIRST AVAILABLE SHOWCASE.

DATASHEET

VOLCANO 100
Dimensions : L.108 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 2.00 m2
Temperature : +0/+2 °C
Total Power Absorption : 2095 W (Ventilated display with built-in group) - 584 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 18 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Power for Remote Group (Evap. T. -10°C) : 1300 W
Gross Weight : 180 kg

VOLCANO 125
Dimensions : L.133 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 2.6 m2
Temperature : +0/+2 °C
Total Power Absorption : 2220 W (Ventilated display with built-in group) - 709 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 18 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1625 W
Gross Weight : 210 kg

VOLCANO 140
Dimensions : L.148 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 2.90 m2
Temperature : +0/+2 °C
Total Power Absorption : 2295 W (Ventilated display with built-in group) - 784 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 18 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1820 W
Gross Weight : 225 kg

VOLCANO 150
Dimensions : L.158 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 3.10 m2
Temperature : +0/+2 °C
Total Power Absorption : 2345 W (Ventilated display with built-in group) - 834 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 1950 W
Gross Weight : 240 kg

VOLCANO 187
Dimensions : L.195.5 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 3.80 m2
Temperature : +0/+2 °C
Total Power Absorption : 3600 W (Ventilated display with built-in group) - 1065 W (Ventilated display with remote group)
Power Absorbed by Lighting : 1 x 58 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 2431 W
Gross Weight : 280 kg

VOLCANO 200
Dimensions : L.208 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 4.10 m2
Temperature : +0/+2 °C
Total Power Absorption : 3660 W (Ventilated display with built-in group) - 1130 W (Ventilated display with remote group)
Power Absorbed by Lighting : 2 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 2600 W
Gross Weight : 300 kg

VOLCANO 250
Dimensions : L.258 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 5.10 m2
Temperature : +0/+2 °C
Total Power Absorption : 3900 W (Ventilated display with built-in group) - 1405 W (Ventilated display with remote group)
Power Absorbed by Lighting : 2 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 3250 W
Gross Weight : 400 kg

VOLCANO 300
Dimensions : L.308 x D.80 x H.204 cm
Lower shelf depth : 53 cm
Shelves Depth : 38 cm (x4)
Exhibition surface area : 6.20 m2
Temperature : +0/+2 °C
Total Power Absorption : 4400 W (Ventilated display with built-in group) - 1770 W (Ventilated display with remote group)
Power Absorbed by Lighting : 2 x 36 W
Climate Class : 3 (Environmental temperature +25 °C; Relative humidity 60%)
Cooling Capacity for Remote Group (Evap. T. -10°C) : 3900 W
Gross Weight : 500 kg

FOR THIS PRODUCT AND FOR ALL SALINA - VULCANO - KIBUK PRODUCTS WE SUGGEST ORDERING THE NECESSARY CAGE TO ENSURE SAFE TRANSPORT.
